Generation and Render of 2D Map with Terrain in Dart + Flutter. (De)Serialization of Generated Map. Part 4.

Generation and Render of 2D Map with Terrain in Dart + Flutter. (De)Serialization of Generated Map. Part 4.


In previous post we finished all the logic related to generation of the map. To be able to apply this feature in real game we need to save and restore the generated map. If we do not do this then each time player starts the game a new map will be generated.


We need to implement (de)serialization logic with following specs:

  • Map is serialized to JSON format
  • Game can convert Map to JSON (serialize).
  • Game can read JSON file and initialize Map (deserialize).


This task is an ideal case for Test Driven Development. We can start adding unit tests that follow such pattern:

  • WorldMap constructor is called with custom input values.
  • WorldMap is serialized to String variable (json).
  • New WorldMap instance is created by deserializing JSON from previous step.
  • Compare that custom values on Step 1 and Step 3 are identical.

In this way we will always know that key properties of the map are saved to JSON and can be later deserialized. All properties that are constant or calculable should not be saved to the JSON.

Serialization Entry Point

The class WorldMap gets new method toJson that will just return a map with two values width and height.

Here is a unit test for it:

  group("(De)serialization", () {
    test("Can serialize and deserialize map dimensions", () {
      var map = WorldMap(width: 5, height: 15);
      var json = map.toJson();
      var newMap = WorldMap.fromJson(json);
      expect(newMap.width, map.width);
      expect(newMap.height, map.height);

Implement missing toJson and fromJson methods:

 Map<String, dynamic> toJson() {
    return {"width": width, "height": height};
  static WorldMap fromJson(Map<String, dynamic> json) {
    return WorldMap(width: json["width"], height: json["height"]);

Serializing List of Tiles

Serializing primitive values was easy. The real task is to serialize all those different types of Tiles into JSON in such way that it will be possible to deserialize it back.

Our class properties look like this:

class WorldMap {
  final int width;
  final int height;
  List<List<MapTile>> tiles;
  LinkedList<MapTile> river;

We need to serialize List> into an array of array with some Maps.

If you look at MapTile class you can notice that it has some primitive values like x and y and an enum with type. This type field will be used in order to distinguish different MapTile in order to call the correct constructor:

class MapTile extends LinkedListEntry<MapTile> {
  final int x;
  final int y;
  DIRECTION_TYPES inDirection;
  DIRECTION_TYPES outDirection;


At first add tests for MapTile (de)serialization:

    test("Can (de)serialize Forest Map Tile", () {
      var tile = ForestMapTile(x: 5, y: 3);
      var newTile = MapTile.fromJson(tile.toJson());
      expect(newTile.type, MAP_TILE_TYPES.FOREST);
      expect(newTile.x, tile.x);
      expect(newTile.y, tile.y);
      expect(newTile.inDirection, isNull);
      expect(newTile.outDirection, isNull);
      expect(newTile, isA<ForestMapTile>());

And then implement toJson and fromJson methods:

  Map<String, dynamic> toJson() {
    return {
      "x": x,
      "y": y,
      "inDirection": directionTypeToString(inDirection),
      "outDirection": directionTypeToString(outDirection),
      "type": mapTileTypeToString(type),

  static MapTile fromJson(Map<String, dynamic> json) {
    var type = mapTileTypeFromString(json["type"]);
    var x = json["x"];
    var y = json["y"];
    var inDirection = directionTypeFromString(json["inDirection"]);
    var outDirection = directionTypeFromString(json["outDirection"]);
    switch (type) {
        return RiverMapTile(x: x, y: y)
          ..inDirection = inDirection
          ..outDirection = outDirection;
        return GrassMapTile(x: x, y: y);
        return ForestMapTile(x: x, y: y);
        return LakeMapTile(x: x, y: y)
          ..inDirection = inDirection
          ..outDirection = outDirection;
        return HomeSettlementMapTile(x: x, y: y);

fromJson method calls specific class constructors in order to return correct instance. The type field is used as a key to determine which class to use.

(De)serializing lists

The MapTile class and its sublings can be processed. Now we need to iterate over tiles to save/restore the map grid.

Add unit test:

test("Can serialize and deserialize map grid with tiles", () {
      var map = WorldMap(width: 3, height: 3);
      map.setTile(ForestMapTile(x: 2, y: 2));
      map.setTile(RiverMapTile(x: 0, y: 1));
      var json = map.toJson();
      var newMap = WorldMap.fromJson(json);
      expect(newMap.tileAtPoint(Point(2, 2)), isA<ForestMapTile>());
      expect(newMap.tileAtPoint(Point(2, 2)), isA<RiverMapTile>());

It will fail as we do not restore *tiles list yet.

Update toJson method to include tiles and river properties:

  Map<String, dynamic> toJson() {
    return {
      "width": width,
      "height": height,
      "tiles": {
        return => mapTile.toJson()).toList();
      "river": => e.toJson()).toList()

And the same for fromJson:

static WorldMap fromJson(Map<String, dynamic> json) {
    List tilesJson = json["tiles"];
    List tiles =<List<MapTile>>((row) {
      return row
          .map<MapTile>((mapTileJson) => MapTile.fromJson(mapTileJson))

    List riverJson = json["river"];
    var river = LinkedList<MapTile>();
    riverJson.forEach((e) {

    var map = WorldMap(width: json["width"], height: json["height"])
      ..tiles = tiles
      ..river = river;
    return map;

Now our tests pass.


We could use some code generation tools available for Dart: json serializable. But my personal preference does not like annotations as they add some kind of magic to the code. Also we would have not to forget to rebuild the generated json deserializer functions on each code change to the classes. At first it seems to be a lot of code but it gives us a lot of flexability and you actually do it once and forget about (de)serialization to JSON.
